| Projector type |
: |
LCD projectors |
| LCD Panel | Panel Size |
: |
16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
| LCD Panel | Pixel |
: |
2,304,000 (1920 x 1200) pixels |
| Light Source |
: |
Laser diode |
| Light Output |
: |
6,200 lm |
| Time until light output declines to 50 % |
: |
20,000 hours (NORMAL/QUIET)/24,000 hours (ECO) |
| Resolution |
: |
WUXGA (1920 x 1200 pixels) |
| Contrast Ratio |
: |
3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
| Screen Size (Diagonal) |
: |
0.76–7.62 m (30–300 in), 16:10 aspect ratio |
| Center-to-corner zone ratio |
: |
85 % |
| Lens |
: |
1.6x manual zoom (throw ratio: 1.09–1.77:1), manual focus lens, F 1.60–2.12, f 15.30 24.64 mm |
| Digital Zoom Extender |
: |
Throw ratio 1.09–2.21:15 (Corresponding value. When used together with optical zoom.) |
| Lens shift | Vertical (from center of screen) |
: |
+44 %, 0 % (manual |
| Lens shift | Horizontal (from center of screen) |
: |
+20 %, -20 % (manual |
| Keystone Correction Range |
: |
Vertical: ±25 °, Horizontal: ±35 ° |
| Terminals | HDMI 1/2 IN |
: |
HDMI 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p6 signal input), CEC supported |
| Terminals | Computer 1 In |
: |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals | Computer 2 In |
: |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals | AUDIO 1/2 IN |
: |
M3 stereo mini-jack x 2 |
| Terminals | Variable Audio Out |
: |
M3 stereo mini-jack x 1 |
| Terminals | Serial In |
: |
D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
| Terminals | DIGITAL LINK/LAN |
: |
RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2], HDCP, Deep Color, 4K/30p signal input) |
| Terminals | LAN |
: |
RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink™ [Class 2] |
| Terminals | USB(VIEWER/WIRELESS/DC OUT) |
: |
USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module, power supply (DC 5 V, maximum 2 A ) |
| Power Supply |
: |
AC 100 V–240 V, 50/60 Hz |
| Power consumption | Maximum power consumption |
: |
370 W (3.9–1.7 A) (395 VA) (Power consumption is 360 W at 200–240 V) |
| Power consumption | On-mode power consumption (Light Power) [Normal] |
: |
335 W (100–120 V), 320 W (200–240 V) |
| Power consumption | On-mode power consumption (Light Power) [Eco] |
: |
240 W (100–120 V), 230 W (200–240 V) |
| Power consumption | On-mode power consumption (Light Power) [Quiet] |
: |
235 W (100–120 V), 225 W (200–240 V) |
| Filter |
: |
Included (Estimated maintenance time: approx. 20,000 hours) |
| Built in Speaker |
: |
10 W monaural |
| Cabinet Materials |
: |
Molded plastic |
| Operation noise |
: |
36 dB (NORMAL/ECO), 26 dB (QUIET) |
| Dimensions (W x H x D) |
: |
399 mm x 115 mm x 348 mm (15 23/32˝ x 4 17/32˝ x 13 11/16˝ ) (not including protruding parts) 399 mm x 133 mm x 348 mm (15 23/32˝ x 5 1/4˝ x 13 11/16˝ ) (with feet at shortest position) |
| Weight with supplied lens |
: |
Approx. 6.9 kg (15.21 lbs) |
