| Terminals | Audio In |
: |
M3 stereo mini-jack x 1 |
| Terminals | Computer In |
: |
D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals | USB (VIEWER/WIRELESS/DC OUT) |
: |
USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module, power supply (DC 5 V, maximum 2 A) |
| Lens |
: |
Fixed zoom, powered focus lens, F = 1.7, f = 2.81 mm, throw ratio: 0.235:1 (16:10 aspect ratio) (Projection distance: 1 cm [1/3 in] for 80-inch image) |
| Power consumption | On-mode power consumption (Light Power) [Normal] |
: |
290 W (AC 100–120V), 280 W (AC 200–240 V) |
| Resolution |
: |
WUXGA (1920 x 1200 pixels) |
| Keystone Correction Range |
: |
Vertical: ±3 °, Horizontal: ±3 ° |
| Power consumption | On-mode power consumption (Light Power) [Eco] |
: |
215 W (AC 100–120V), 205 W (AC 200–240 V) |
| Power consumption | On-mode power consumption (Light Power) [Quiet] |
: |
210 W (AC 100–120V), 200 W (AC 200–240 V) |
| Terminals | HDMI™ IN 1/IN 2 |
: |
HDMI™ 19-pin x 2 (Compatible with HDCP 1.4, Deep Color, 4K/30p6 signal input), CEC supported |
| Installation |
: |
Ceiling/floor, front/rear, free 360-degree installation |
| Protocol versions |
: |
IPv4 |
| Screen Size (Diagonal) |
: |
2.03–3.05 m (80–120 in) (16:10 aspect ratio) |
| Terminals | HDMI™ OUT |
: |
HDMI™ 19-pin x 1 (Compatible with HDCP 1.4, Deep Color, 4K/30p6 signal output) |
| Contrast Ratio |
: |
3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
| Dimensions (W x H x D) |
: |
495 mm x 160 mm x 421 mm (19 1/2˝ x 6 19/64˝ x 16 37/64˝) (excluding feet and protrusions),495 mm x 176 mm x 421 mm (19 1/2˝ x 6 15/16˝ x 16 37/64˝) (with feet at shortest position) |
| Light Source |
: |
Laser diodes |
| Built-in Speaker |
: |
10 W monaural |
| LCD Panel | Panel Size |
: |
16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
| Operating Environment |
: |
Operating temperature: 0–45 °C (32–113 °F)*11, Operating humidity: 20–80 % (no condensation) |
| LCD Panel | Pixels |
: |
2,304,000 (1920 x 1200) pixels |
| Cabinet Materials |
: |
Molded plastic |
| Projector type |
: |
LCD projector |
| Applicable Software |
: |
Multi Monitoring & Control Software, Logo Transfer Software, Projector Network Setup Software, Presenter Light Software for Windows®, Wireless Projector App for iOS/Android™ |
| Center-to-corner zone ratio |
: |
85 % |
| Time until light output declines to 50 % |
: |
20,000 hours (NORMAL/QUIET)/24,000 hours (ECO) |
| Light Output |
: |
5,200 lm |
| Operation noise |
: |
35 dB (NORMAL/ECO), 26 dB (QUIET) |
| Filter |
: |
Included (Estimated maintenance time: approx. 20,000 hours) |
| Digital Zoom Extender |
: |
Throw ratio 0.235–0.288:15 (16:10 aspect ratio) (Corresponding value) |
| Weight with supplied lens |
: |
Approx. 9.5 kg (20.9 lbs) |
| Power Supply |
: |
AC 100 V–240 V, 50/60 Hz |
| Control function via LAN |
: |
PJLink™ [Class 2], Crestron Connected™, AMX Device Discovery |
| Terminals | Variable Audio Out |
: |
M3 stereo mini-jack x 1 |
| Power consumption | Maximum power consumption |
: |
325 W (3.4–1.4 A) (330 VA) (Power consumption is 310 W at AC 200–240 V) |
| Terminals | Serial In |
: |
D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
| Terminals | LAN |
: |
RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink™ [Class 2] |
| Terminals | LAN/DIGITAL LINK |
: |
RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2],HDCP, Deep Color, 4K/30p6 signal input) |
